GSM18E Series
18W AC-DC Reliable Green Medical Adaptor
GSM18E Series Main Features:
Protections: Short circuit / Overload /
Over voltage
LED indicator for power on
Models:
Manufacturer:
Type:
Other features:
GSM36U05-P1J / GSM36U07-P1J
GSM36U09-P1J / GSM36U12-P1J
GSM36U15-P1J / GSM36U18-P1J
GSM36U24-P1J / GSM36U48-P1J
MEAN WELL
Adaptor
Medical safety approved (2 x MOPP)
according to ANSI/AAMI ES60601-1/-1-11
Extremely low leakage current
2 pole USA plugs, Class II power unit
No load power consumption <0.1W
Energy efficiency Level VI(except 5~9V
for Level V)
3 years warranty
Quote Request
| GSM18E05-P1J | GSM18E07-P1J | GSM18E09-P1J | GSM18E12-P1J | GSM18E15-P1J | GSM18E18-P1J | GSM18E24-P1J | GSM18E48-P1J | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wattage | 15 | 15 | 18 | 18 | 18 | 18 | 18 | 18 | ||||||||
| Input Voltage | 80~264VAC 113~370VDC | 80~264VAC 113~370VDC | 80~264VAC 113~370VDC | 80~264VAC 113~370VDC | 80~264VAC 113~370VDC | 80~264VAC 113~370VDC | 80~264VAC 113~370VDC | 80~264VAC 113~370VDC | ||||||||
| Output Current | 3A | 2A | 2A | 1.5A | 1.2A | 1A | 0.75A | 0.375A | ||||||||
| Output Voltage | 5V | 7.5V | 9V | 12V | 15V | 18V | 24V | 48V | ||||||||
| Dimensions | 79x54x33 | 79x54x33 | 79x54x33 | 79x54x33 | 79x54x33 | 79x54x33 | 79x54x33 | 79x54x33 | ||||||||
| Working Temperature | -25~+60°C | |||||||||||||||
| Satety Standards | IEC 60601-1:2005+A1+A2; IEC 60601-1-11:2015+A1, TUV BS EN/ EN 60601-1:2006+A1+A12+A2; BS EN/ EN 60601-1-11:2015+A1, EAC TP TC 004 approved | |||||||||||||||
