Home / AC-DC Adaptor / GST25A
GST25A Series
25W AC-DC Reliable Green Industrial Adaptor
GST25A Series Main Features:
Protections: Short circuit / Overload /
Over voltage
No load power consumption <0.075W
Models:
Manufacturer:
Type:
Other features:
GST25A05-P1J / GST25A07-P1J
GST25A09-P1J / GST25A12-P1J
GST25A15-P1J / GST25A18-P1J
GST25A24-P1J / GST25A28-P1J
GST25A48-P1J
MEAN WELL
Adaptor
Fanless design with -30~+70°C work
-ing temperature
Universal AC Input / Full range
3 pole AC inlet IEC320-C14
Pass LPS
Energy efficiency Level VI
Fully enclosed plastic case
Class I power (without earth pin)
Meet EISA 2007
3 years warranty
Quote Request
| GST25A05-P1J | GST25A07-P1J | GST25A09-P1J | GST25A12-P1J | GST25A15-P1J | GST25A18-P1J | GST25A24-P1J | GST25A28-P1J | GST25A48-P1J | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wattage | 20 | 22 | 23 | 25 | 25 | 25 | 25 | 25 | 25 | |||||||
| Input Voltage | 85~264VAC | 85~264VAC | 85~264VAC | 85~264VAC | 85~264VAC | 85~264VAC | 85~264VAC | 85~264VAC | 85~264VAC | |||||||
| Output Current | 4A | 2.93A | 2.55A | 2.08A | 1.66A | 1.38A | 1.04A | 0.89A | 0.52A | |||||||
| Output Voltage | 5V | 7.5V | 9V | 12V | 15V | 18V | 24V | 28V | 48V | |||||||
| Dimensions | 93x54x36 | 93x54x36 | 93x54x36 | 93x54x36 | 93x54x36 | 93x54x36 | 93x54x36 | 93x54x36 | 93x54x36 | |||||||
| Working Temperature | -30~+70°C | |||||||||||||||
| Satety Standards | UL60950-1, CSA C22.2, TUV EN60950-1, BMSI CNS14336, CCC GB4943, PSE J60950-1, AS/NZS 60950.1 approved | |||||||||||||||
| EMC Standards | Compliance to EN55022 class B, EN61000-3-2,3, FCC PART 15 / CISPR22 class B, CAN ICES-3(B)/NWB-3(B),CNS13438 class B, GB9254, GB17625.1 Compliance to EN61000-4-2,3,4,5,6,8,11 light industry level, criteria A | |||||||||||||||
