RCB-1600 Series
19 Inch Rack Power Supplies 1440–1584W
RCB-1600 Series Main Features:
Charger for lead-acid batteries (Gel, flooded and AGM) and Li-ion batteries (lithium iron and lithium manganese)
Built-in I2C interface, PMBus protocol
Models:
Manufacturer:
Type:
Other features:
RCP-1600-12 / RCP-1600-24
RCP-1600-48
MEAN WELL
Rack Power Supplies
Built-in default 3 stage charging curves
and programmable curve
Protections: Battery under voltage /
Battery no connection / Short circuit /
Over voltage / Over temperature
Output voltage and current programmable
Built-in OR-ing FET support hot swap
(hot plug)
Active current sharing up to 8000W for
one 19b rack shelf
Forced air cooling by built-in DC fan
Optional conformal coating
5 years warranty
Quote Request
[wpforms id="1665" title="false"]
| RCP-1600-12 | RCP-1600-24 | RCP-1600-48 | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wattage | 1440 | 1584 | 1584 | |||||||||||||
| Input Voltage | 90~264VAC | 90~264VAC | 90~264VAC | |||||||||||||
| Output Current | 0~100A | 0~55A | 0~27.5A | |||||||||||||
| Output Voltage | 12V | 24V | 48V | |||||||||||||
| Output Voltage Options | Single | Single | Single | |||||||||||||
| DC Output Adjustment | 11.5~15V | 23.5~30V | 47.5~58.8V | |||||||||||||
| Dimensions | 300x85x41 | 300x85x41 | 300x85x41 | |||||||||||||
| Working Temperature | -30~+70°C | |||||||||||||||
| Satety Standards | UL60950-1, TUV EN60950-1 approved | |||||||||||||||
| EMC Standards | Compliance to EN55022 (CISPR22) Conduction Class B, Radiation Class A ; EN61000-3-2,-3 Compliance to EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN500082-2), light industry level, criteria A | |||||||||||||||
