NPP-750 Series
Chargers 722.4–759.36W
NPP-750 Series Main Features:
NPP-750 is a miniaturized dual-purpose charge and power supply
Models:
Manufacturer:
Type:
Other features:
NPP-750-12 / NPP-750-24
NPP-750-48
MEAN WELL
Charger
Multi-function single unit battery charger
or power supply operation modes selectable
Output voltage and current adjustable
via potentiometer
3-stage charging curve for charging mode
Multiple protections: short circuit/ Over
load/ Over voltage/ Over temperature
Thermal controlled DC fan for noise reduction
Remote ON/OFF control
Suitable for lead-acid (Pb) batteries
3 years warranty
Quote Request
| NPP-750-12 | NPP-750-24 | NPP-750-48 | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wattage | 722.4 | 756 | 759.36 | |||||||||||||
| Input Voltage | 90~264VAC | 90~264VAC | 90~264VAC | |||||||||||||
| Output Current | 43A | 22.5A | 11.3A | |||||||||||||
| DC Output Adjustment | 10.5~21V | 21~42V | 42~80V | |||||||||||||
| Dimensions | 230x158x67 | 230x158x67 | 230x158x67 | |||||||||||||
| Working Temperature | -30~+70°C | |||||||||||||||
| Satety Standards | CB IEC62368-1, IEC60335-1/2-29, Dekra BS EN/EN62368-1, BS EN/EN60335-1/2-29, UL62368-1, EAC TP TC 004 approved | |||||||||||||||
| EMC Standards | BS EN/EN55032(CISPR32), BS EN/EN55014-1, BS EN/EN61000-3-2, BS EN/EN61000-3-3 | |||||||||||||||
