Home / AC-DC Programmable Power Type / RSP-3000
RSP-3000 Series
Enclosed Power Supplies 2400–3000W
RSP-3000 Series Main Features:
Conformally Coated
Built-in active PFC function, PF >0.95
Protections: Short circuit/ Overload/ Over voltage/ Over Temp./ Fan alarm
Models:
Manufacturer:
Type:
Other features:
RSP-3000-12 / RSP-3000-24
RSP-3000-48 / RSP-3000-48CC
MEAN WELL
Programmable Power Supplies
High power density 15.6W/in³
AC input 180~264VAC only
Built-in 12V/0.1A auxiliary output
Alarm signal output (TTL signal &
relay contact)
Output voltage can be trimmed be
-tween 20~110% of the rated output voltage
Current sharing up to 3 units
Remote ON/OFF control & remote sense
3 years warranty
Quote Request
| RSP-3000-12 | RSP-3000-24 | RSP-3000-48 | RSP-3000-48CC | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wattage | 2400 | 3000 | 3000 | 3000 | ||||||||||||
| Input Voltage | 180~264VAC 254~370VDC | 180~264VAC 254~370VDC | 180~264VAC 254~370VDC | 180~264VAC 254~370VDC | ||||||||||||
| Output Current | 0~200A | 0~125A | 0~62.5A | 0~62.5A | ||||||||||||
| Output Voltage | 12V | 24V | 48V | 48V | ||||||||||||
| Output Voltage Options | Single | Single | Single | Single | ||||||||||||
| DC Output Adjustment | 10.8~13.2V | 22~28V | 43~56V | |||||||||||||
| Dimensions | 278x177.8x63.5 | 278x177.8x63.5 | 278x177.8x63.5 | 278x177.8x63.5 | ||||||||||||
| Working Temperature | -20~+70°C | |||||||||||||||
| Satety Standards | UL62368-1, CSA C22.2 , TUV EN62368-1 , IS13252 Part1 IEC60950 1, No. 62368-1 BS EN/ , , BSMI CNS14336-1 AS/NZS62368.1- EAC TP TC 004 approved | |||||||||||||||
| EMC Standards | EN55022 class B, EN61000-3-2,3 EN61000-4-2,3,4,5,6,8,11 | |||||||||||||||
