EPS-15 Series

Open Frame Power Supplies 10–16.5W

EPS-15

EPS-15 Series Main Features:

No load power consumption<0.3W

1.8" 2.5" compact size

Protections: Short circuit / Overload / Over voltage

Models:

Manufacturer:

Type:

Other features:

EPS-15-3.3 / EPS-15-5
EPS-15-7.5 / EPS-15-12
EPS-15-15 / EPS-15-24
EPS-15-27 / EPS-15-36
EPS-15-48

MEAN WELL

Open Frame Power Supplies

Universal AC Input / Full range

Cooling by free air convection

LED indicator for power on

3 years warranty

Quote Request

    EPS-15-3.3EPS-15-5EPS-15-7.5EPS-15-12EPS-15-15EPS-15-24EPS-15-27EPS-15-36EPS-15-48
    Wattage1015151516.515151515
    Input Voltage85~264VAC 120~370VDC85~264VAC 120~370VDC85~264VAC 120~370VDC85~264VAC 120~370VDC85~264VAC 120~370VDC85~264VAC 120~370VDC85~264VAC 120~370VDC85~264VAC 120~370VDC85~264VAC 120~370VDC
    Output Current0~3.3A0~3.3A0~2.2A0~1.38A0~1.1A0~0.69A0~0.615A0~0.46A0~0.34A
    Output Voltage3.3V5V7.5V12V15V24V27V36V48V
    Output Voltage OptionsSingleSingleSingleSingleSingleSingleSingleSingleSingle
    DC Output Adjustment3.1~3.6V4.75~5.5V7.13~8.25V10.8~13.5V13.5~16.5V21.6~27V24.3~29.7V32.4~39.6V43.2~52.8V
    Dimensions63.5x45.7x2263.5x45.7x2263.5x45.7x2263.5x45.7x2263.5x45.7x2263.5x45.7x2263.5x45.7x2263.5x45.7x2263.5x45.7x22
    Working Temperature-30~+70°C
    Satety StandardsUL60950-1, TUV EN60950-1 approved
    EMC StandardsCompliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3, EN61000-4-2,3,4,5,6,8,11, EN55024, heavy industry level, criteria A
