Home / AC-DC Open Frame Type / IRM-03
IRM-03 Series
Open Frame Power Supplies 3–4W
IRM-03 Series Main Features:
Universal AC input / Full range
Protections: Short circuit / Overload / Over voltage
Models:
Manufacturer:
Type:
Other features:
IRM-03-5 / IRM-03-9
IRM-03-12 / IRM-03-15
IRM-03-24
MEAN WELL
Open Frame Power Supplies
Isolation class II
Cooling by free air convection
Comply with EN55022 Class B without
any additional components
Compact size
No load power consumption <0.075W
3 years warranty
Quote Request
| IRM-03-5 | IRM-03-9 | IRM-03-12 | IRM-03-15 | IRM-03-24 | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wattage | 3 | 3 | 3 | 3 | 3 | |||||||||||
| Input Voltage | 85~305VAC | 85~305VAC | 85~305VAC | 85~305VAC | 85~305VAC | |||||||||||
| Output Current | 600mA | 333mA | 250mA | 200mA | 125mA | |||||||||||
| Output Voltage | 5V | 9V | 12V | 15V | 24V | |||||||||||
| Output Voltage Options | Single | Single | Single | Single | Single | |||||||||||
| Dimensions | 37x24x15 | 37x24x15 | 37x24x15 | 37x24x15 | 37x24x15 | |||||||||||
| Working Temperature | -30-+85°C | |||||||||||||||
| Satety Standards | UL60950-1, TUV EN60950-1 Approved, Meet IEC60601-1, EN60335-1, EN61558-1/-2-16 | |||||||||||||||
| EMC Standards | Compliance to EN55022 (CISPR22) Class B , EN61000-3-2-3, Compliance to EN61000-4-2,3,4,5,6,8,11 ; EN55024, heavy industry level(surge L-N : 1KV), criteria A | |||||||||||||||
