Home / AC-DC Security&Specific Type / PSC-100
PSC-100 Series
Chargers 100W
PSC-100 Series Main Features:
Din Rail Mounted
UPS Function
Protections: Short circuit / Overload / Over voltage
Models:
Manufacturer:
Type:
Other features:
PSC-35A / PSC-35B
PSC-35A-C / PSC-35B-C
MEAN WELL
Chargers
Universal AC input / Full range
5”x3” compact size
Battery low protection / Battery
reverse polarity protection by fuse
Relay contact signal for AC OK and
Battery low
Cooling by free air convection
2 years warranty
Quote Request
| PSC-100A | PSC-100B | PSC-100A-C | PSC-100B-C | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wattage | 100 | 100 | 100 | 100 | ||||||||||||
| Input Voltage | 90~264VAC 127~370VDC | 90~264VAC 127~370VDC | 90~264VAC 127~370VDC | 90~264VAC 127~370VDC | ||||||||||||
| Output Current | 0~7.0A, 0~2.5A | 0~3.50A, 0~1.25A | 0~7.0A, 0~2.5A | 0~3.50A, 0~1.25A | ||||||||||||
| Output Voltage | 13.8V | 27.6V | 13.8V | 27.6V | ||||||||||||
| Output Voltage Option | Dual | Dual | Dual | Dual | ||||||||||||
| DC Output Adjustment | Dual | Dual | Dual | Dual | ||||||||||||
| Dimensions | 13.8V:12~15V;27.6V:24~29V | 13.8V:12~15V;27.6V:24~29V | 13.8V:12~15V;27.6V:24~29V | 13.8V:12~15V;27.6V:24~29V | ||||||||||||
| Working Temperature | -20~+70°C | |||||||||||||||
| Satety Standards | UL60950-1, TUV EN60950-1 approved | |||||||||||||||
| EMC Standards | EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11 | |||||||||||||||
