ERDN-40 Series
Enclosed Power Supplies 40W
ERDN-40 Series Main Features:
Support 1+1 and N+1 redundancy system
2 channels input and 1 output
Models:
Manufacturer:
Type:
Other features:
ERDN40-12 / ERDN40-24
ERDN40-48
MEAN WELL
Enclosed Power Supplies
Suitable for redundancy operation
of 12V/24V/48 system
Output current up to 40A
Cooling by free air convection
-40~+80C ultra-wide operating
temperature (+60C derating)
Built-in 2 channels DC OK signal and
alarm relay contact
3 years warranty
Quote Request
| ERDN-40-12 | ERDN-40-24 | ERDN-40-48 | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Input Voltage | 12V | 24V | 48V | |||||||||||||
| Output Current | 0-40A | 0-40A | 0-40A | |||||||||||||
| Output Voltage | 12V | 24V | 48V | |||||||||||||
| Output Voltage Option | Single | Single | Single | |||||||||||||
| DC Output Adjustment | 0-40A | 0-40A | 0-40A | |||||||||||||
| Dimensions | 97 x 99 x 36 | 97 x 99 x 36 | 97 x 99 x 36 | |||||||||||||
| Working Temperature | -40 - +80°C | |||||||||||||||
| Satety Standards | IEC62368-1, UL62368-1,approved EAC TP TC 004 | |||||||||||||||
| EMC Standards | EN55032(CISPR32), EN61000-4-2,3,4,5,6,8 | |||||||||||||||
