Home / DC-DC Enclosed Type / SD-350
SD-350 Series
350W Single Output DC-DC Converter
SD-350 Series Main Features:
2:1 wide input range
Protections: Short Circuit / Overload / Over voltage / Over temperature
Models:
Manufacturer:
Type:
Other features:
SD-350B-5 / SD-350B-12
SD-350B-24 / SD-350B-48
SD-350C-5 / SD-350C-12
SD-350C-24 / SD-350C-48
SD-350D-5 / SD-350D-12
SD-350D-24 / SD-350D-48
MEAN WELL
Enclosed Power Supplies
1500VAC I/O isolation
Forced air cooling by built-in DC Fan
100% full load burn in test
24V and 48V input voltage design refer to LVD
2 years warranty
Quote Request
| SD-350B-5 | SD-350B-12 | SD-350B-24 | SD-350B-48 | SD-350C-5 | SD-350C-12 | SD-350C-24 | SD-350C-48 | SD-350D-5 | SD-350D-12 | SD-350D-24 | SD-350D-48 | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wattage | 285 | 330 | 350.4 | 350.4 | 300 | 330 | 350.4 | 350.4 | 300 | 330 | 350.4 | 350.4 | ||||
| Input Voltage | 20~36Vdc | 20~36Vdc | 20~36Vdc | 20~36Vdc | 36~72Vdc | 36~72Vdc | 36~72Vdc | 36~72Vdc | 72~144Vdc | 72~144Vdc | 72~144Vdc | 72~144Vdc | ||||
| Output Current | 57A | 27.5A | 14.6A | 7.3A | 60A | 27.5A | 14.6A | 7.3A | 60A | 27.5A | 14.6A | 7.3A | ||||
| Output Voltage | 5V | 12V | 24V | 48V | 5V | 12V | 24V | 48V | 5V | 12V | 24V | 48V | ||||
| Output Voltage Options | Single | Single | Single | Single | Single | Single | Single | Single | Single | Single | Single | Single | ||||
| Dimensions | 215x115x50 | 215x115x50 | 215x115x50 | 215x115x50 | 215x115x50 | 215x115x50 | 215x115x50 | 215x115x50 | 215x115x50 | |||||||
| Working Temperature | -20~+60°C | |||||||||||||||
| Satety Standards | EAC TP TC 004 approved, design refer to AS/NZS 62368.1 | |||||||||||||||
| EMC Standards | Compliance to BS EN/EN55032 (CISPR32) Class B, EAC TP TC 020 | |||||||||||||||
