Home / AC-DC DIN Rail Type / SDR-480P
SDR-480P Series
DIN Rail Power Supplies 480W
SDR-480P Series Main Features:
Current sharing up to 3840W(7+1)
Built-in active PFC function, PF>0.93
High efficiency up to 94%
Protections: Short circuit / Overload / Over voltage / Over temperature
Models:
Manufacturer:
Type:
Other features:
SDR-480P-24 / SDR-480P-48
MEAN WELL
DIN Rail Power Supplies
Universal AC input / Full range
Can be installed on DIN rail TS-35 / 7.5 or 15
Cooling by free air convection
UL508(industrial control equipment) approved
EN6100-2( EN50082-2) industrial immunity level
Built-in DC OK relay contact
150% peak load capacity
Comply with GL and SEMI f47
3 years warranty
Quote Request
| SDR-480P-24 | SDR-480P-48 | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wattage | 480 | 480 | ||||||||||||||
| Input Voltage | 90-264VAC 127-370VDC | 90-264VAC 127-370VDC | ||||||||||||||
| Output Current | 0~10A | 0~10A | ||||||||||||||
| Output Voltage | 24 | 48 | ||||||||||||||
| Output Voltage Option | Single | Single | ||||||||||||||
| DC Output Adjustment | 24-28V | 48-55V | ||||||||||||||
| Dimensions | 85.5x125.2x128.5 | 85.5x125.2x128.5 | ||||||||||||||
| Working Temperature | -25~+70°C | |||||||||||||||
| Satety Standards | UL508, TUV EN60950-1, GL approved | |||||||||||||||
| EMC Standards | Compliance to EN55022 class B, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN50082-2), EN61204-3, Heavy industry level, SEMI F47, GL | |||||||||||||||
