LED Driver Outdoor Constant Current
ELG Series
WATTAGE:
75W~300W
FEATURES:
100~305VAC input range
IP67/IP65 design for indoor or outdoor installations
Function options:
output adjustable via potentiometer; 3 in
1 dimming (0~10Vdc or 10V PWM signal or resistance, dim-
to-off); smart timer dimming; DALI; auxiliary DC output (ELG
-150 BE-Type)
Type "HL" LED drivers for use in Class I, Division 2
hazardous (Classified) location luminaries
Suitable for LED street lighting and outdoor LED lighting
5 years warranty
ELG-C Series
WATTAGE:
75W~300W
FEATURES:
100~305VAC input range
Constant current (C.C.) output
Built-in active PFC function
No load/standby power consumption <0.5W
IP67/IP65 design for indoor or outdoor installations
Function options:
output adjustable via potentiometer; 3 in
1 dimming (0~10Vdc or 10V PWM signal or resistance, dim-
to-off); smart timer dimming; DALI; auxiliary DC output (ELG
-150-C BE-Type)
HVG Series
WATTAGE:
65W~480W
FEATURES:
Wide input range 180~528VAC
Metal case, IP67/IP65 design for indoor or outdoor installations
Built-in active PFC function
Function options:output adjustable via potentiometer;
3 in 1 dimming (0~10Vdc or 10V PWM signal or resistance,
dim-to-off); timer dimming; smart timer dimming
Type "HL" LED drivers for use in Class I, Division 2
hazardous (Classified) location luminaries (except for HVG-65)
Suitable for LED street lighting and outdoor LED
lighting applications
HVG(C) Series
WATTAGE:
65W~1000W
FEATURES:
Wide input range 180~528VAC
Metal case, IP67/IP65 design for indoor or outdoor installations
Built-in active PFC function
Function options:output adjustable via potentiometer;
3 in 1 dimming (0~10Vdc or 10V PWM signal or resistance,
dim-to-off); timer dimming; smart timer dimming
Type "HL" LED drivers for use in Class I, Division 2
hazardous (Classified) location luminaries (except
for HVGC-65/100)
Suitable for LED street lighting and outdoor LED
lighting applications
XBG Series
WATTAGE:
100W~240W
FEATURES:
Wide range 100~305VAC mains input
Built-in active PFC function and constant power mode
AC input cable with waterproof connector for flexible using
Surge protection: 6 KV /4KV
Protections: short circuit, over voltage, over temperature
