LED Driver Outdoor with Dimming
ELG Series
WATTAGE:
75W~300W
FEATURES:
100~305VAC input range
IP67/IP65 design for indoor or outdoor installations
Function options:
output adjustable via potentiometer; 3 in
1 dimming (0~10Vdc or 10V PWM signal or resistance, dim-
to-off); smart timer dimming; DALI; auxiliary DC output (ELG
-150 BE-Type)
Type "HL" LED drivers for use in Class I, Division 2
hazardous (Classified) location luminaries
Suitable for LED street lighting and outdoor LED lighting
5 years warranty
ELG-C Series
WATTAGE:
75W~300W
FEATURES:
100~305VAC input range
Constant current (C.C.) output
Built-in active PFC function
No load/standby power consumption <0.5W
IP67/IP65 design for indoor or outdoor installations
Function options:
output adjustable via potentiometer; 3 in
1 dimming (0~10Vdc or 10V PWM signal or resistance, dim-
to-off); smart timer dimming; DALI; auxiliary DC output (ELG
-150-C BE-Type)
HLG Series
WATTAGE:
40W~600W
FEATURES:
90~305VAC input, built-in active PFC function
96% high efficiency (HLG-600H)
Metal case, IP67/IP65 design for indoor or outdoor installations
Function options:
output adjustable via potentiometer; 3 in
1 dimming (1~10Vdc or 10V PWM signal or resistance);
timer dimming
Type "HL" LED drivers for use in Class I, Division 2
hazardous (Classified) location luminaries
Suitable for LED street lighting, outdoor LED lighting and
general outdoor applications with high IP requirement
HLG-C Series
Model information
WATTAGE:
70W~480W
FEATURES:
90~305VAC input, built-in active PFC function
Constant current output with high output voltage >60VDC
Metal case, IP67/IP65 design for indoor or outdoor installations
Function options:output adjustable via potentiometer;
3 in 1 dimming (1~10Vdc or 10V PWM signal or resistance,
dim-to-off); timer dimming; smart timer dimming
Type "HL" LED drivers for use in Class I, Division 2
hazardous (Classified) location luminaries (HLG-240H
-C/320H-C only)
Suitable for LED street lighting and outdoor LED lighting
XLG Series
WATTAGE:
20W~320W
FEATURES:
Wide input range 100~305VAC (90~305VAC for XLG-20)
Constant power mode with adjustable output
current (Constant current mode for XLG-20)
Built-in active PFC function and Efficiency up to 90%
Dimming functions: 3 in 1
Protections: Short circuit/ Over voltage/ Over temperature
Surge protection with 6KV(L/N-FG)/4KV(L-N); 4KV(L/N-FG)/
2KV (L-N) for XLG-20
